Double probe sockets Full digital A/B scan portable cheapest Ophthalmic Ultrasound

Product Categories

Zhengzhou Medbes International Trading CO.,LTD.

Contact Now

Name: Double probe sockets Full digital AB scan portable cheapest Ophthalmic Ultrasound
Brand: Medbes
Price: 4560 USD

Brand Name : Medbes

Model Number : M-ODU5

Certification : CE,ISO

Place of Origin : China

MOQ : 1pc

Price : 4560usd

Payment Terms : Western Union, T/T

Supply Ability : 666pcs per month

Delivery Time : 7days

Packaging Details : Carton

A mode probe : 10MHZ, imported probe with fixation light

B mode probe : 10MHz, imported transducer.

Monitor : 10.4 inch high resolution LCD screen

Probe sockets : Double probe sockets

Display mode : B, B/B, 4B, B/A, A

Gains range : 0--120dB

Dynamic range : 30-100dB, visual and adjustable

Gray : 256

Intelligent TGC adjustment : 8 segments

Build-in D disk : 4GB, save mass data, images, reports, etc

Report function : print screen, IOL report, case report with picture, etc

Contact Now

Full digital A/B scan portable cheapest Ophthalmic Ultrasound

Double probe sockets Full digital A/B scan portable cheapest Ophthalmic Ultrasound

A scan parameter:

Resolution:	0.01mm.
Gain adjustable:	0-120dB.
Measurement range:	12-43mm(1640m/s).
Accuracy:	±0.02mm.
Eye mode:	normal/aphakia/dense cataract/PMMA, Acrylic & Silicon for Pseudo Phakic eyes.
Measuring Mode:	Contact and Immersion, automatic and manual.
Measurement methods:	A single-point measurement(under A mode); five-point measurement(under A mode).
Calculation:	std. deviation, average, automatical measuring 8 groups and average, accompany waveform, results correctable.
IOL Formula:	SRK-II, SRK-T, BINKHORST,HOLLADAY, HOFFER-Q, HAIGIS.

B scan parameter:

Scan mode:	High accuracy stepping motor drive sector scan.
Scan Angle:	53°.
Display Depth:	0~56mm.
Gray:	256.
Depth seletion:	8.
Frame correlation:	4.
Edge enhancement:	4.
Compression Curve:	4.
Post-processing:	8.
image storage:	100 frames permanent image storage.
General Measurement:	multi-electronic-rule to measure distance, circumference, area(trace method, ellipse method),volume (ellipse method), angle , histogram, profile , stenosis and curvature etc.

Standard Configuration:

1	Main unit: 1 pc
2	10MHz mechanical sector B probe: 1 pc.
3	10MHz A probe : 1 pc.
4	Network cable: 1pc
5	Foot switch:1 pc
6	Workstation software

Optional Configuration:

Double probe sockets Full digital A/B scan portable cheapest Ophthalmic Ultrasound

Packing Size:360*340*460mm
Gross Weight:8.5kgs
Product can be delivered within 7days.

Double probe sockets Full digital A/B scan portable cheapest Ophthalmic Ultrasound Images
